Simplify Line Segment Ratios: A, B, C, D On A Line

Ever found yourself staring at a geometry problem with points lined up like ducks in a row? You know, points A, B, C, and D all chilling on the same straight line, and you're given these fancy ratios like $AB: BD = 1: 4$ and $AC: CD = 7: 13$. Your mission, should you choose to accept it, is to work out the ratio $AB : BC : CD$ in its simplest form. Sounds like a bit of a brain teaser, right? But fear not! With a little bit of algebraic magic and a clear head, we can untangle these ratios and find that sweet, simplified answer. This isn't just about numbers; it's about understanding how parts relate to the whole, a fundamental concept in mathematics that pops up in all sorts of places, from design and architecture to even cooking!

Let's break down what we're dealing with. We have four points, A, B, C, and D, positioned sequentially on a single straight line. This means they are in a fixed order, and the distances between them add up. Our first clue is $AB: BD = 1: 4$. This tells us that the segment AB is one part of a larger segment BD, which is composed of four parts. Crucially, BD is made up of BC and CD. So, we can express this relationship algebraically. Let's say the length of AB is $x$. Then, according to the ratio, the length of BD must be $4x$. Now, remember that BD is actually the sum of BC and CD. So, $BD = BC + CD$. This gives us $4x = BC + CD$. We're not done yet! Our second clue is $AC: CD = 7: 13$. Similar to the first ratio, this means that for every 7 units of length in AC, there are 13 units in CD. Let's introduce another variable here. If we let the length of CD be $13y$, then the length of AC must be $7y$. Again, AC is made up of AB and BC. So, $AC = AB + BC$. This means $7y = AB + BC$. Now we have a system of equations and relationships that we need to solve simultaneously. The key is to find a way to relate these different segments (AB, BC, CD) using our given information. We want to express everything in terms of a common unit or variable so we can compare them directly. This is where the real problem-solving begins, moving from understanding the problem statement to actively manipulating the given information to find the solution.

To truly work out $AB : BC : CD$, we need to get these segments talking to each other. We have $AB: BD = 1: 4$. Since $BD = BC + CD$, we can rewrite this as $AB : (BC + CD) = 1: 4$. This means $4 imes AB = 1 imes (BC + CD)$, so $4AB = BC + CD$. Our second piece of information is $AC: CD = 7: 13$. Since $AC = AB + BC$, we can rewrite this as $(AB + BC) : CD = 7: 13$. This implies $13 imes (AB + BC) = 7 imes CD$, which expands to $13AB + 13BC = 7CD$. Now we have two main equations: (1) $4AB = BC + CD$ and (2) $13AB + 13BC = 7CD$. Our goal is to find the ratio $AB : BC : CD$. Let's try to express BC and CD in terms of AB, or perhaps express AB and BC in terms of CD, or some combination. From equation (1), we can express CD as $CD = 4AB - BC$. Let's substitute this into equation (2): $13AB + 13BC = 7(4AB - BC)$. Expanding this gives us $13AB + 13BC = 28AB - 7BC$. Now, let's gather the AB terms on one side and the BC terms on the other. Subtracting $13AB$ from both sides gives $13BC = 15AB - 7BC$. Adding $7BC$ to both sides gives $20BC = 15AB$. Now we can find a relationship between AB and BC! Dividing both sides by 5, we get $4BC = 3AB$. This means AB = rac{4}{3} BC. We've made a significant step! We can now express AB in terms of BC. Let's use this to find CD in terms of BC as well. We know from equation (1) that $CD = 4AB - BC$. Substituting our new finding AB = rac{4}{3} BC into this equation, we get CD = 4(rac{4}{3} BC) - BC. This simplifies to CD = rac{16}{3} BC - BC. Combining the terms, we get CD = (rac{16}{3} - 1) BC = (rac{16}{3} - rac{3}{3}) BC = rac{13}{3} BC. So now we have AB = rac{4}{3} BC and CD = rac{13}{3} BC. We are looking for the ratio $AB : BC : CD$. We can write this as rac{4}{3} BC : BC : rac{13}{3} BC. Since BC is a common factor, we can divide each term by BC: rac{4}{3} : 1 : rac{13}{3}. To get rid of the fractions and express this in its simplest integer form, we can multiply all parts of the ratio by 3. This gives us $4 : 3 : 13$. Let's double-check this! If $AB=4$, $BC=3$, and $CD=13$, then $BD = BC + CD = 3 + 13 = 16$. The ratio $AB: BD$ would be $4: 16$, which simplifies to $1: 4$. This matches our first given ratio! Now let's check the second ratio. $AC = AB + BC = 4 + 3 = 7$. The ratio $AC: CD$ would be $7: 13$. This also matches our second given ratio! Our answer is correct.

Understanding the Building Blocks: Segments and Ratios

When we talk about points $A, B, C,$ and $D$ lying in order on a straight line, we're essentially dealing with a one-dimensional space where distances are additive. This setup is fundamental in many areas of mathematics, from basic geometry to coordinate systems. The problem gives us two key pieces of information about the relationships between the lengths of the segments formed by these points: $AB: BD = 1: 4$ and $AC: CD = 7: 13$. Our ultimate goal is to find the ratio $AB : BC : CD$. To achieve this, we need to leverage the properties of segments on a line and the definition of ratios. A ratio $a: b$ means that for every $a$ units of the first quantity, there are $b$ units of the second quantity. It's a comparison of two values. When dealing with line segments, it's often helpful to assign variables to represent their lengths. Let's denote the lengths of the segments as follows: $AB$, $BC$, and $CD$. Since the points are in order on a straight line, we can express larger segments as sums of smaller adjacent ones. For instance, $AC = AB + BC$, and $BD = BC + CD$. Also, $AD = AB + BC + CD$. This additive property is crucial for solving these types of problems.

The first ratio, $AB: BD = 1: 4$, tells us a direct relationship between the length of the segment AB and the length of the segment BD. If we let the length of AB be $k$, then the length of BD must be $4k$. Using our additive property, we know that $BD = BC + CD$. So, we can write $4k = BC + CD$. This equation links the segments BC and CD to the length $k$ (which is related to AB). The second ratio, $AC: CD = 7: 13$, gives us another relationship. If we let the length of CD be $7m$, then the length of AC must be $13m$. Wait, I made a mistake in variable assignment. Let's be consistent. If $AC: CD = 7: 13$, it means that for some common multiplier, $AC = 7m$ and $CD = 13m$. Now, using the additive property, $AC = AB + BC$. So, we have $7m = AB + BC$. This equation relates AB and BC to $m$ (which is related to CD). Now we have two sets of relationships: From $AB: BD = 1: 4$, we have $BD = 4AB$. Since $BD = BC + CD$, we get $4AB = BC + CD$. From $AC: CD = 7: 13$, we have AC = rac{7}{13} CD. Since $AC = AB + BC$, we get AB + BC = rac{7}{13} CD. We have three unknown lengths ($AB, BC, CD$) and we want to find their ratio. It's often easiest to express all unknown lengths in terms of a single variable. Let's try to express AB and BC in terms of CD. From AB + BC = rac{7}{13} CD, we can't directly solve for AB or BC without more information. This is where substitution and careful algebraic manipulation become our best friends. We need to combine the information from both ratios. Let's use the first equation $4AB = BC + CD$ and the second relation derived from the ratio $AC:CD = 7:13$, which is $AB + BC = AC$. The ratio $AC: CD = 7: 13$ means AC = rac{7}{13} CD. So, AB + BC = rac{7}{13} CD. Now we have two equations involving $AB, BC,$ and $CD$: (1) $4AB = BC + CD$ and (2) AB + BC = rac{7}{13} CD. We want to find $AB: BC: CD$. Let's try to eliminate one variable. From equation (1), we can express $BC$ as $BC = 4AB - CD$. Substitute this expression for $BC$ into equation (2): AB + (4AB - CD) = rac{7}{13} CD. Combining the terms involving $AB$, we get 5AB - CD = rac{7}{13} CD. Now, let's isolate the term with $AB$: 5AB = CD + rac{7}{13} CD. To combine the terms on the right side, we find a common denominator: 5AB = rac{13}{13} CD + rac{7}{13} CD = rac{20}{13} CD. Now, we can solve for $AB$ in terms of $CD$: AB = rac{1}{5} imes rac{20}{13} CD = rac{4}{13} CD. So, we have found a relationship between AB and CD: AB = rac{4}{13} CD. This means that for every 4 units of AB, there are 13 units of CD. Now we need to find BC in terms of CD. We can use the equation $BC = 4AB - CD$. Substitute AB = rac{4}{13} CD into this equation: BC = 4(rac{4}{13} CD) - CD = rac{16}{13} CD - CD. Finding a common denominator, we get BC = rac{16}{13} CD - rac{13}{13} CD = rac{3}{13} CD. Now we have expressed both AB and BC in terms of CD: AB = rac{4}{13} CD and BC = rac{3}{13} CD. We are looking for the ratio $AB : BC : CD$. Substituting our expressions, we get rac{4}{13} CD : rac{3}{13} CD : CD. Since $CD$ is a common factor, we can divide each term by $CD$: rac{4}{13} : rac{3}{13} : 1. To express this ratio with integers, we multiply each part by 13: (rac{4}{13} imes 13) : (rac{3}{13} imes 13) : (1 imes 13). This gives us $4 : 3 : 13$. This is our answer in its simplest form. It's a beautiful illustration of how algebraic representation can simplify complex ratio problems.

Deciphering the Ratios: A Step-by-Step Algebraic Approach

Let's dive deeper into the algebraic mechanics of solving this ratio problem. We are given that points A, B, C, and D lie in order on a straight line. This ordering is key because it means that segment lengths are additive: $AC = AB + BC$, $BD = BC + CD$, and $AD = AB + BC + CD$. Our first piece of information is $AB: BD = 1: 4$. This can be translated into an equation. If we let the length of AB be $x$, then the length of BD is $4x$. So, $BD = 4AB$. Since $BD = BC + CD$, we can write this as $4AB = BC + CD$. This is our first fundamental equation. Our second piece of information is $AC: CD = 7: 13$. Similarly, this means that for some common multiplier, $AC = 7k$ and $CD = 13k$. More usefully, we can express the relationship as rac{AC}{CD} = rac{7}{13}, which implies $13AC = 7CD$. Using the additive property $AC = AB + BC$, we can substitute this into the equation: $13(AB + BC) = 7CD$. Expanding this gives us $13AB + 13BC = 7CD$. This is our second fundamental equation. Now we have a system of two linear equations with three variables ($AB, BC, CD$):

1. $4AB = BC + CD$
2. $13AB + 13BC = 7CD$

Our goal is to find the ratio $AB : BC : CD$. To do this, we need to express two of the variables in terms of the third, or find relationships that allow us to determine their relative sizes. Let's try to express $BC$ and $CD$ in terms of $AB$. From equation (1), we can express $CD$ as $CD = 4AB - BC$. Now, substitute this expression for $CD$ into equation (2):

$13AB + 13BC = 7(4AB - BC)$

Expand the right side:

$13AB + 13BC = 28AB - 7BC$

Now, we want to group terms involving $AB$ and terms involving $BC$. Let's move all $BC$ terms to the left side and all $AB$ terms to the right side. Add $7BC$ to both sides:

$13AB + 13BC + 7BC = 28AB$ $13AB + 20BC = 28AB$

Now, subtract $13AB$ from both sides:

$20BC = 28AB - 13AB$ $20BC = 15AB$

We have found a direct relationship between $BC$ and $AB$. To simplify it, divide both sides by 5:

$4BC = 3AB$

This tells us that AB = rac{4}{3} BC. Now we have $AB$ in terms of $BC$. Let's find $CD$ in terms of $BC$ as well. We can use equation (1): $CD = 4AB - BC$. Substitute AB = rac{4}{3} BC into this equation:

CD = 4(rac{4}{3} BC) - BC CD = rac{16}{3} BC - BC CD = (rac{16}{3} - rac{3}{3}) BC CD = rac{13}{3} BC

So, we have AB = rac{4}{3} BC and CD = rac{13}{3} BC. We want to find the ratio $AB : BC : CD$. Substituting our expressions:

rac{4}{3} BC : BC : rac{13}{3} BC

Since $BC$ is common to all terms, we can divide each term by $BC$:

rac{4}{3} : 1 : rac{13}{3}

To express this ratio in its simplest whole number form, we multiply each part by the least common multiple of the denominators, which is 3:

(rac{4}{3} imes 3) : (1 imes 3) : (rac{13}{3} imes 3)

$4 : 3 : 13$

This is the simplified ratio $AB : BC : CD$. This step-by-step algebraic approach ensures that we systematically use all the given information to arrive at the correct and simplest form of the ratio.

Verifying the Solution: Checking the Ratios

Once we've arrived at a potential answer for the ratio $AB : BC : CD$, it's always a good practice, especially in mathematics, to verify the solution. This means plugging our derived ratio back into the original conditions to see if they hold true. Our calculated ratio is $AB : BC : CD = 4 : 3 : 13$. Let's assume, for simplicity, that the lengths of these segments are exactly proportional to these numbers. So, we can let $AB = 4k$, $BC = 3k$, and $CD = 13k$ for some positive constant $k$. The points are in order on a straight line, so these lengths are directly additive.

Let's check the first condition: $AB: BD = 1: 4$. First, we need to find the length of segment BD. Since B, C, and D are in order, $BD = BC + CD$. Substituting our assumed lengths: $BD = 3k + 13k = 16k$. Now, let's form the ratio $AB: BD$: $AB : BD = 4k : 16k$. We can divide both sides by $k$ (since $k$ must be positive, as lengths are positive) to get $4 : 16$. Simplifying this ratio by dividing both numbers by their greatest common divisor, which is 4, we get $1 : 4$. This matches the first given ratio exactly! So, our calculated ratio is consistent with the first condition.

Now, let's check the second condition: $AC: CD = 7: 13$. First, we need to find the length of segment AC. Since A, B, and C are in order, $AC = AB + BC$. Substituting our assumed lengths: $AC = 4k + 3k = 7k$. The length of CD is given as $13k$. Now, let's form the ratio $AC: CD$: $AC : CD = 7k : 13k$. Dividing both sides by $k$, we get $7 : 13$. This matches the second given ratio exactly! Our calculated ratio is also consistent with the second condition.

Since our derived ratio $AB : BC : CD = 4 : 3 : 13$ satisfies both original conditions, we can be confident that it is the correct answer in its simplest form. The process of verification confirms the accuracy of our algebraic manipulations and our understanding of the problem. This final check is an indispensable part of mathematical problem-solving, ensuring that the conclusions drawn are sound.

Conclusion: Mastering Segment Ratios

We've successfully navigated the problem of finding the ratio $AB : BC : CD$ given $AB: BD = 1: 4$ and $AC: CD = 7: 13$ for points A, B, C, and D in order on a straight line. Through a systematic algebraic approach, we translated the ratio information into equations and used substitution to solve for the relationships between the segments. The key was to express $AB$ and $BC$ in terms of $CD$ (or any other segment) and then simplify the resulting proportions. We found that AB = rac{4}{13} CD and BC = rac{3}{13} CD, which led us to the simplified integer ratio $AB : BC : CD = 4 : 3 : 13$. The verification step confirmed that this ratio perfectly satisfies the initial conditions. This exercise highlights the power of algebraic methods in geometry and ratio problems. Understanding how to manipulate ratios and segment lengths is a foundational skill that extends to many other mathematical concepts.
